  • Nauja prekė   Technica PPC2380-J6412-IP69K 23,8" IP69K/IP68 visiškai nerūdijančio plieno, PCAP lietimui jautriu ekranu, be ventiliatoriaus, panelinis kompiuteris, Intel Elkhart Lake J6412
    Nauja prekė   Technica PPC2380-J6412-IP69K 23,8" IP69K/IP68 visiškai nerūdijančio plieno, PCAP lietimui jautriu ekranu, be ventiliatoriaus, panelinis kompiuteris, Intel Elkhart Lake J6412 1
    Nauja prekė   Technica PPC2380-J6412-IP69K 23,8" IP69K/IP68 visiškai nerūdijančio plieno, PCAP lietimui jautriu ekranu, be ventiliatoriaus, panelinis kompiuteris, Intel Elkhart Lake J6412 2

    Technica PPC2380-J6412-IP69K 23,8" IP69K/IP68 visiškai nerūdijančio plieno, PCAP lietimui jautriu ekranu, be ventiliatoriaus, panelinis kompiuteris, Intel Elkhart Lake J6412

    Kodas: PPC2380-J6412-IP69K
    Užsakoma prekė
    Pasiteirauti/Užsakyti
    23.8” IP69K/IP68 Full Stainless Steel, PCAP Touch, Fanless Panel PC, Intel Elkhart Lake J6412
    Gamintojas
    Technica House
    Pritaikymo sritis
    Pilnai atsparus vandeniui
    Kilmės šalis
    Taivanas
    Sertikatas
    IP69K/IP68
  • LCD Panel 23.8"
    CPU Intel Celeron Elkhart Lake J6412 CPU, Quad-Core, up to 2.60 GHz, TDP 10W
    Chipset SoC integrated
    System Memory DDR4-2666/2933/3200, 1 x SO-DIMM, up to 32GB
    BIOS AMI
    COM 2 x RS-232 with 2 meter long M12 type water-proof IP69K cable (max.)
    USB

    6 x USB 2.0 with 2 meter long M12 type water-proof IP69K cable (max.), USB 3.0 2 meter M12 IP69K cable (Optional)
    Ethernet 2 x LAN with 2 meter long M12 type water-proof IP69K cable (max.)
    Display

    -
    Audio -
    Storage 1 x SATA 3.0, 1 x NVMe M.2
    Expansion

    1 x M.2 (Key-M, 2280, PCIe x2 NVMe/ SATA) NVMe is default
    1 x M.2 (Key-B, 3052, PCIE/USB 3.0 + USB 2.0) USB 3.0 is default
    1 x Mini-PCIe (PCIe + USB 2.0/ mSATA) PCIe + USB 2.0 is default
    Others 1 x Vent M12 connector (for air pressure release)
    Touch Screen True-Flat PCAP Touch or Resistive Touch (Optional), Anti-UV/Anti-IR protection/Optical Bonding (Optional)
    Front Bezel Full IP69K/IP68 Stainless steel housing
    Power Supply

    1 x DC-12V Input port with 2 meter long M12 type water-proof IP69K cable with Power adapter included
    9-36VDC-IN wide range, w/o Power adapter (optional)
    Power Consumption -
    Watchdog Timer Watch dog timer support
    Operating Temperature ‐20°C~ +60°C
    Relative Humidity 10%~90% (non‐condensing)
    Vibration -
    Dimensions 594.5 x 368.9 x 53 mm
    Weight 10.5 Kg
    Certifications CE/FCC
    EOS Support Windows 10, Windows 11, Linux
    Mounting VESA mounting supportd (75 x 75 or 100 x 100 mm)
