  • Nauja prekė   Technica TBOX-TGL-6C Įterptinė (embedded) sistema be ventiliatoriaus su Tiger Lake i3-1115G4/i5-1135G7/i7-1195G7 procesoriumi, maks. 6 COM ir 8 USB prievadais
    Nauja prekė   Technica TBOX-TGL-6C Įterptinė (embedded) sistema be ventiliatoriaus su Tiger Lake i3-1115G4/i5-1135G7/i7-1195G7 procesoriumi, maks. 6 COM ir 8 USB prievadais 1

    Technica TBOX-TGL-6C Įterptinė (embedded) sistema be ventiliatoriaus su Tiger Lake i3-1115G4/i5-1135G7/i7-1195G7 procesoriumi, maks. 6 COM ir 8 USB prievadais

    Kodas: TBOX-TGL-6C
    Užsakoma prekė
    Pasiteirauti/Užsakyti
    Fanless Embedded System with Tiger Lake i3-1115G4/i5-1135G7/i7-1195G7 Processor with Max. 6 x COM ports, 8 x USB ports
    Gamintojas
    Technica House
    Kilmės šalis
    Taivanas
  • CPU Intel Tiger Lake i3-1115G4/i5-1135G7/i7-1195G7 processor
    Chipset CPU Integrated
    System Memory DDR4-3200 MHz, 1 x non-ECC SO-DIMM, up to 32GB
    BIOS AMI
    COM 3 x RS-232, 1 x RS-232/485 (Optional extra 2 x RS-232)
    USB

    6 x USB 3.0 (Optional extra 2 x USB 2.0)
    Ethernet 2 x RJ-45, Intel GBE LAN Chip (10/100/1000 Mbps)
    PoE -
    Display

    2 x HDMI
    Digital I/O
    Audio 1 x Line-Out + MIC 2 in 1 4.0mm Jack
    Storage 1 x SATA 3.0, 1 x NVMe M.2
    Expansion

    1 x M.2 Key-M Slot (PCIe x4 NVMe / SATA SSD, 2280) SATA is default
    1 x M.2 Key-E Slot (PCIE + USB 2.0, Support Wifi + BT, 2230)
    1 x Mini PCI-E Slot (PCIE +USB 2.0, Support Wifi +3G/4G, with 1 x nano-SIM card slot)
    Others 1 x Power LED Header 1 x Power Button Header 1 x System Reset Header 1 x HDD LED Header 1 x CPU FAN Header 2 x GSPI Header
    Power Supply

    1 x DC 12V power input connector with lock
    Optional: Phoenix contact connector
    Optional: Wide range 9-36V
    Watchdog Timer With Watchdog Timer
    Construction -
    Operating Temperature -20°C ~ 70°C
    Relative Humidity 10% ~ 95% RH non-condensing
    Vibration -
    Shock -
    Dimensions 182.12 x 130 x 59.85 mm
    Weight 1.20 Kg
    Certifications CE/FCC
    EOS Support -
    Software Support Windows 10, Windows 11, Linux
    Mounting VESA mount 100 x 100 mm, DIN Rail with DIN Rail bracket (Optional) Wall Mount with Wall Mount bracket (Optional)
