  • New item   Advantech AMAX-5001 4-channel High Speed Trigger and Latch EtherCAT Module
    New item   Advantech AMAX-5001 4-channel High Speed Trigger and Latch EtherCAT Module 1

    Advantech AMAX-5001 4-channel High Speed Trigger and Latch EtherCAT Module

    Code: AMAX-5001
    Ordered item
    Order
    Manufacturer
    Advantech
    Made in
    Taiwan
  • • 4-channel 32-bit encoder counters
    • Encoder input mode : CW/CCW , Pulse/Direction, A/B Phase
    • Encoder input signal : A, B, Z
    • Encoder input frequency : 5 MHz (Maximum)
    • 4-channel trigger DO for position compare
    • Trigger output frequency : 10 kHz; latch input frequency : 10kHz
    • Trigger output mode : sink, source, TTL
    • Supports trigger delay time setting for each channel
    • 4-channel latch DI for position latch
